3 Pol - P4CDL003
P4CDL003
- Protection cap for female connectors against dust, dirt and water
- Double sided attachment features
- Engagement directly to silicion sealing ensures high protection level
- Water tightness according AK test guideline for automotive connectors (PG23)
- Loss proof and permanent protection of the terminals
- Intuitive assembly
suitable for:
Tyco Superseal 1.5
Version
3 Pol
Request individual advice
Technical characteristics
Technical data sheet
Colour
black
Material
PBT GF20
Temperature resistance
-40°C up to +130°C
Chemical resistance
Alcohol, weak alkalis, solvents, fuels, mineral oils, grease/oils
Tightness
PG23
Order number
P4CDL003
Shipping time
On Demand
Advantages
Staub und Schmutz
Staub und Schmutz
Due to the wide variety of outlet directions and ability to maximize space with low profile solutions, our dress covers allow cables to easily route in their defined direction. For optimal use of the installation space.
Bauraum
Bauraum
Due to the wide variety of outlet directions and ability to maximize space with low profile solutions, our dress covers allow cables to easily route in their defined direction. For optimal use of the installation space.
Intuitive Montage
Schutz der Leitungen
Reduzierung von Schwingungen
Einsatz auf engstem Raum (Form D und E)
