Product image Flexible ferrules - GPN 205
Application Flexible protective sleeves - GPN 205
Drawing Flexible Protection Sleeves - GPN 205
Protective Caps - GPN 205
The GPN 205 protective caps are suitable for bolts, external threads, and pins. The flexible material in combination with internal clamping surfaces help to accommodate larger tolerances.
The linear contact across the surfaces also reduces material abrasion in case of any sharp edges on the counter-piece. The easy-to-grip, knurled collar and clamping surfaces ensure a firm fit and low-abrasion removal.- Protective caps for external protection
- Production in accordance with ISO 16232 in a specially designed cleanroom possible
Virgin material
Dimensions
Colour
yellow
Material
EVA
Technical data sheet
|
Applicable for
|
Dimensions
|
||||
|---|---|---|---|---|---|
|
Item
|
D
|
G
|
CAD
|
Order no.
|
|
| GPN 205 G 1/8 EVA, yellow | 9,7 | 12,2 | show | 20518000000 | |
|
|
|||||
| GPN 205 K 10 x 12 EVA, yellow | 10 | 12,2 | show | 20510120000 | |
|
|
|||||
| GPN 205 K 12 x 12 EVA, yellow | 12 | 12,2 | show | 20512120000 | |
|
|
|||||
| GPN 205 G 1/4 EVA, yellow | 13,2 | 14,2 | show | 20514000000 | |
|
|
|||||
| GPN 205 K 14 x 14 EVA, yellow | 14 | 14,2 | show | 20514140000 | |
|
|
|||||
| GPN 205 K 16 x 8 EVA, yellow | 16 | 8 | show | 20516800000 | |
|
|
|||||
| GPN 205 K 16 x 16 EVA, yellow | 16 | 16,2 | show | 20516160000 | |
|
|
|||||
| GPN 205 G 3/8 EVA, yellow | 16,7 | 18,2 | show | 20538000000 | |
|
|
|||||
| GPN 205 K 18 x 18 EVA, yellow | 18 | 18,2 | show | 20518180000 | |
|
|
|||||
| GPN 205 K 20 x 20 EVA, yellow | 20 | 20,2 | show | 20520200000 | |
|
|
|||||
| GPN 205 G 1/2 EVA, yellow | 21 | 21,2 | show | 20512000000 | |
|
|
|||||
| GPN 205 K 22 x 22 EVA, yellow | 22 | 22,2 | show | 20522220000 | |
|
|
|||||
| GPN 205 G 5/8 EVA, yellow | 23 | 22,2 | show | 20558000000 | |
|
|
|||||
| GPN 205 G 3/4 EVA, yellow | 26,4 | 22,2 | show | 20534000000 | |
|
|
|||||
| GPN 205 G 1 EVA, yellow | 33,3 | 23,2 | show | 20510000000 | |
|
|
|||||
Dimensions in mm.
Information on materials, colours, designs and use of our products can be found on the website and in chapter 3´ Materials and application´.
Application guide
|
Applicable for metric thread
|
||||||
|---|---|---|---|---|---|---|
|
Item
|
fine thread
|
Standard thread
|
Pipe thread
|
|||
| GPN 205 G 1 EVA, yellow | G 1 | |||||
| GPN 205 G 1/8 EVA, yellow | G 1/8 | |||||
| GPN 205 G 5/8 EVA, yellow | G 5/8 | |||||
| GPN 205 G 3/8 EVA, yellow | G 3/8 | |||||
| GPN 205 G 1/2 EVA, yellow | G 1/2 | |||||
| GPN 205 G 1/4 EVA, yellow | G 1/4 | |||||
| GPN 205 G 3/4 EVA, yellow | G 3/4 | |||||
| GPN 205 K 10 x 12 EVA, yellow | M 10 x 1 | M 10 x 1,25 | M 10 | |||
| GPN 205 K 12 x 12 EVA, yellow | M 12 x 1 | M 12 x 1,25 | M 12 x 1,5 | M 12 | ||
| GPN 205 K 14 x 14 EVA, yellow | M 14 x 1 | M 14 x 1,5 | M 14 | |||
| GPN 205 K 16 x 8 EVA, yellow | M 16 x 1 | M 16 x 1,5 | M 16 | |||
| GPN 205 K 16 x 16 EVA, yellow | M 16 x 1 | M 16 x 1,5 | M 16 | |||
| GPN 205 K 18 x 18 EVA, yellow | M 18 x 1 | M 18 x 1,5 | M 18 | |||
| GPN 205 K 20 x 20 EVA, yellow | M 20 x 1 | M 20 x 1,5 | M 20 | |||
| GPN 205 K 22 x 22 EVA, yellow | M 22 x 1 | M 22 x 1,5 | M 22 | |||
This application table represents guideline values. We would be pleased to send you free samples.
Quality advantages
More versatile.
Flexible material in combination with internal clamping surfaces help to accomodate larger tolerances.
Cleaner.
Production in accordance with VDA Band 19 and ISO 16232 in our cleanroom on request.
Better.
Suitable for studs, external threads, and pins. Easy-to-grip knurled collar and clamping surfaces for firm fit and low-abrasion removal.
