Grip Caps - GPN 210

The GPN 210 grip caps are suitable for protecting pipe ends, hoses and bolts. The internal sealing lip ensures an optimal clamping fit and high sealing function. The ergonomically shaped grip tab enables easy handling during fitting and removal.


  • Grip caps for external protection
  • Production in accordance with ISO 16232 in a specially designed cleanroom possible
more advantages

Dimensions

Colour
gelb
Material
EVA
Materials and Applications
mm inch
Applicable for
Dimensions
Item
D
G
M
CAD
Order no.
GPN 210 ZL 4 x 21 EVA, gelb 0.157 0.831 1.346 21004210000
GPN 210 ZL 5 x 20 EVA, gelb 0.197 0.787 1.437 21005200000
GPN 210 ZL 6 x 10 EVA, gelb 0.236 0.394 1.043 21006100000
GPN 210 ZL 6 x 20 EVA, gelb 0.236 0.787 1.437 21006200000
GPN 210 ZL 7 x 20 EVA, gelb 0.276 0.787 1.457 21007200000
GPN 210 ZL 8 x 10 EVA, gelb 0.315 0.394 1.043 21008100000
GPN 210 ZL 8 x 20 EVA, gelb 0.315 0.787 1.437 21008200000
GPN 210 ZL 9 x 20 EVA, gelb 0.354 0.787 1.437 21010100000
GPN 210 ZL 10 x 20 EVA, gelb 0.394 0.787 1.437 21010200000
GPN 210 ZL 11 x 20 EVA, gelb 0.433 0.787 1.437 21011200000
GPN 210 ZL 12 x 10 EVA, gelb 0.472 0.394 1.043 21012100000
GPN 210 ZL 12 x 20 EVA, gelb 0.472 0.787 1.437 21012200000
GPN 210 ZL 12 x 30 EVA, gelb 0.472 1.181 1.831 21012300000
GPN 210 ZL 13 x 20 EVA, gelb 0.512 0.787 1.437 21013200000
GPN 210 ZL 14 x 10 EVA, gelb 0.551 0.394 1.043 21014100000
GPN 210 ZL 14 x 20 EVA, gelb 0.551 0.787 1.437 21014200000
GPN 210 ZL 15 x 20 EVA, gelb 0.591 0.787 1.437 21015200000
GPN 210 ZL 16 x 10 EVA, gelb 0.63 0.394 1.043 21016100000
GPN 210 ZL 16 x 20 EVA, gelb 0.63 0.787 1.437 21016200000
GPN 210 ZL 17 x 20 EVA, gelb 0.669 0.787 1.437 21017200000
GPN 210 ZL 18 x 10 EVA, gelb 0.709 0.394 1.043 21018100000
GPN 210 ZL 18 x 20 EVA, gelb 0.709 0.787 1.437 21018200000
GPN 210 ZL 19 x 20 EVA, gelb 0.748 0.787 1.437 21019200000
GPN 210 ZL 20 x 10 EVA, gelb 0.787 0.394 1.043 21020100000
GPN 210 ZL 20 x 20 EVA, gelb 0.787 0.787 1.437 21020200000
GPN 210 ZL 20 x 30 EVA, gelb 0.787 1.181 1.831 21020300000
GPN 210 ZL 22 x 20 EVA, gelb 0.866 0.787 1.437 21022200000
GPN 210 ZL 24 x 20 EVA, gelb 0.945 0.787 1.437 21024200000
GPN 210 ZL 26 x 20 EVA, gelb 1.024 0.787 1.437 21026200000
GPN 210 ZL 28 x 20 EVA, gelb 1.102 0.787 1.437 21028200000
GPN 210 ZL 30 x 20 EVA, gelb 1.181 0.787 1.437 21030200000

Dimensions in mm

Information on materials, colours, drawings and use of our articles can be found on pages 166/167.

Quality advantages

Saves time.
Saves time.
With ergonomically designed removal tab for easy handling.
Cleaner.
Cleaner.
Production in accordance with VDA Band 19 and ISO 16232 in our specially equipped cleanroom on request.
Better.
Better.
Suitable for pipe ends, hoses, and studs. With circumferential sealing lip for a firm fit.
