Finned Plugs - GPN 320

The finned plugs GPN 320 protect round pipe ends according to DIN EN 10220, DIN EN 10255 and DIN EN ISO 1127 against damage and dirt. The solid design is suitable for high demands. The ribbed plugs ensure a firm fit on the application even with dimension tolerances in the pipe and have a high-quality appearance thanks to their grained top surface and chamfered edges.


  • Ribbed plugs for internal protection
more advantages

Dimensions

Colour
schwarz
Material
PE-LLD
Applicable for pipe dimensions
Dimensions
Item
A
T min
T max
B
C
H
M
CAD
Order no.
GPN 320 GL 10 1-2 PE-LLD, schwarz 10 1 2 5 8,5 11 15 32000100000
GPN 320 GL 12 1-2 PE-LLD, schwarz 12 1 2 7 10,5 11 15 32000120000
GPN 320 GL 13 1-2 PE-LLD, schwarz 13 1 2 8 11,5 11 15 32000130000
GPN 320 GL 14 1-2 PE-LLD, schwarz 14 1 2 9 12,5 11 15 32000140000
GPN 320 GL 15 1-2 PE-LLD, schwarz 15 1 2 10 13,5 11 15 32000150000
GPN 320 GL 16 1-2 PE-LLD, schwarz 16 1 2 11 14,5 11 15 32000160000
GPN 320 GL 18 1-2 PE-LLD, schwarz 18 1 2 13 16,5 11 15 32000180000
GPN 320 GL 20 1-2 PE-LLD, schwarz 20 1 2 15 18,5 11 15 32000200000
GPN 320 GL 22 1-2 PE-LLD, schwarz 22 1 2 16 20,5 14 19 32000220000
GPN 320 GL 25 1-2 PE-LLD, schwarz 25 1 2 19 23,5 14 19 32000250000
GPN 320 GL 27 1-2 PE-LLD, schwarz 27 1 2 21 25,5 14 19 32000270000
GPN 320 GL 28 1-2 PE-LLD, schwarz 28 1 2 22 26,5 14 19 32000280000
GPN 320 GL 30 1-2 PE-LLD, schwarz 30 1 2 24 28,5 14 19 32000300000
GPN 320 GL 32 1-2 PE-LLD, schwarz 32 1 2 26 30,5 14 19 32000320000
GPN 320 GL 34 1-2 PE-LLD, schwarz 34 1 2 28 32,5 14 19 32000340000
GPN 320 GL 35 1-2 PE-LLD, schwarz 35 1 2 29 33,5 14 19 32000350000
GPN 320 GL 36 1-2 PE-LLD, schwarz 36 1 2 30 34,5 14 19 32000360000
GPN 320 GL 38 1-2 PE-LLD, schwarz 38 1 2 32 36,5 14 19 32000380000
GPN 320 GL 40 1-2 PE-LLD, schwarz 40 1 2 34 38,5 14 19 32000400000
GPN 320 GL 42 1-2 PE-LLD, schwarz 42 1 2 36 40,5 14 19 32000420000
GPN 320 GL 45 1-2 PE-LLD, schwarz 45 1 2 39 43,5 14 19 32000450000
GPN 320 GL 48 1-2 PE-LLD, schwarz 48 1 2 42 46,5 14 19 32000480000
GPN 320 GL 50 1-2 PE-LLD, schwarz 50 1 2 43 48,5 17 22 32000500000
GPN 320 GL 55 1-2 PE-LLD, schwarz 55 1 2 48 53,5 17 22 32000550000
GPN 320 GL 60 1-2 PE-LLD, schwarz 60 1 2 53 58,5 17 22 32000600000
GPN 320 GL 60 2-3 PE-LLD, schwarz 60 2 3 51 56,5 17 22 32006030000
GPN 320 GL 70 2-3 PE-LLD, schwarz 70 2 3 61 66,5 17 22 32000700000
GPN 320 GL 70 3-4 PE-LLD, schwarz 70 3 4 59 64,5 17 22 32007030000
GPN 320 GL 76 2-3 PE-LLD, schwarz 76 2 3 67 72,5 17 22 32000760000
GPN 320 GL 76 3-4 PE-LLD, schwarz 76 3 4 65 70,5 17 22 32007630000
GPN 320 GL 90 2-3 PE-LLD, schwarz 90 2 3 81 86,5 17 22 32000900000
GPN 320 GL 90 3-4 PE-LLD, schwarz 90 3 4 79 84,5 17 22 32009030000
GPN 320 GL 102 2-3 PE-LLD, schwarz 102 2 3 93 98,5 17 22 32001020000
GPN 320 GL 102 3-4 PE-LLD, schwarz 102 3 4 91 96,5 17 22 32010230000

Dimensions in mm

Information on materials, colours, drawings and use of our articles can be found on pages 166/167.

Quality advantages

Better fit.
Better fit.
To close off round pipes in accordance with DIN EN 10220, DIN EN 10255, and DIN EN ISO 1127.
More robust.
More robust.
Solid design for increased demands.
More versatile.
More versatile.
Ribs on the shank provide a secure fit even with varying tube tolerances.
Better.
Better.
High visual appeal due to grained top surface finish and chamfered edges.
