Screw Plugs - GPN 720 Type A

The GPN 720 Type A screw plugs are suitable for many different internal threads. The thick-walled design is suitable for high demands. The flat head and coordinated head diameter enable countersinking in the bore hole.


  • Screw plugs for internal protection
  • Also available in Type B with sealing cone
  • Two sustainable variants made from post-consumer recyclate available
more advantages

Dimensions

Colour
recycling blau
Material
PCR-PE
Materials and Applications
mm inch
Applicable for
Dimensions
Item
K
H
SW
SW Zoll
CAD
Order no.
GPN 720 / 0052 PCR-PE, recycling blau M 16 0.63 8 7200052RB61
GPN 720 / 1596 PCR-PE, recycling blau 1 1/2 - 11 1/2 NPT 0.886 53/64 7201596RB61
GPN 720 / 1597 PCR-PE, recycling blau 1 1/4 - 11 1/2 NPT 0.866 19 3/4 7201597RB61
GPN 720 / 1598 PCR-PE, recycling blau 1 - 11 1/2 NPT 0.835 5/8 7201598RB61
GPN 720 / 1599 PCR-PE, recycling blau 3/4 - 14 NPT 0.669 9/16 7201599RB61
GPN 720 / 1600 PCR-PE, recycling blau 1/2 - 14 NPT 0.65 3/8 7201600RB61
GPN 720 / 1601 PCR-PE, recycling blau 3/8 - 18 NPT 0.512 8 5/16 7201601RB61
GPN 720 / 1602 PCR-PE, recycling blau 1/4 - 18 NPT 0.492 1/4 7201602RB61
GPN 720 / 1766 PCR-PE, recycling blau 1/8 - 27 NPT 0.335 5 7201766RB61
GPN 720 / 1767 PCR-PE, recycling blau 1/4 - 18 NPT 0.492 6 7201767RB61
GPN 720 / 1769 PCR-PE, recycling blau 3/4 - 14 NPT 0.669 14 7201769RB61
GPN 720 / 1770 PCR-PE, recycling blau 1 - 11 1/2 NPT 0.835 17 7201770RB61
GPN 720 / 1771 PCR-PE, recycling blau 1 1/2 - 11 1/2 NPT 0.886 22 7201771RB61
GPN 720 / 8016 PCR-PE, recycling blau M 30 0.886 19 7208016RB61

Dimensions in mm

Information on materials, colours, drawings and use of our articles can be found on pages 166/167.

Quality advantages

More robust.
More robust.
Thick-walled design for higher demands.
Better.
Better.
Immersible screw plug with hexagonal socket.
More resource-saving.
More resource-saving.
The plastic used consists of 100 % recycled material.
